This powerful small temperature control unit with electronic flow control can be used with water or oil operation, and also in the leak-stopper mode. The TT-188 is a best-seller.
Explore The Product View Full Products RangeGk0300704 Switch "ON-OFF" unit (green)
Gk0300704 Switch "ON-OFF" unit (green)
Gk0300600 Double switch (green)
Gk0500100 Press button Green
Gk0300500 Lamp safety thermostat
Gk0300400 Lamp level control - unit off
Gk0300100 Indication lamp motor overload (red)
Gk0300100 Indication lamp flow control failure (red)
Gk0200100/Gk0200200 Swtich VAC/pressure device
Fa0800326 Digital temperature controller MP-888
GG0300001 Horn
Gk0701801 Main switch 40A Gk700800 Main switch 63A
Dc0100000 Steering rollers Ø 50 mm
Bb03000000 Screw fasterner (complete)
De0300200 Drain angle 90º
Wf0100000 Isolation set
Gm0100800 Heating element 3x380-420v 50Hz / Gm0100700 Heating element 3x200-230v 50/60Hz / Gm0100900 Heating element 3 x 440-480 V 60Hz / Gm0101100 Heating Clips / Db0200500 Gasket
Wa1000030 Temperature probe FeKo
Db0500200 Seal for tank cover
Ca2000500 Screw cap refull pipe 1"
Df0200110 - Solenoid valve R1/4" 18Bar / Df0200910 - Repair kit for solenoid valve R1/4" 18Bar/ Df0200600 - Spare coil for solenoid valve R3/8" & 1/4"
Df0200000 - Solenoid valve R3/8", for water cooling / Df0200905 - Repair kit fitting for solenoid valves 3/8" & ½" / Df0200600 - Spare coil for solenoid valve R3/8" & 1/4"
De0100400 Water filter R3/8", with mesh bottom
EB0201200 Pump type E with pump motor 0.75kW
De0701600 Manometer - 1 bis 6 bar / De0701201 Fixing clips for manometer Ø 40 mm
EB0201200 Pump type E with pump motor 0.75kW
Sensor flow measurement
De0100400 Water filter R3/8", with mesh bottom
Ca2000500 Screw cap refull pipe 1"
De0300200 Drain angle 90º
Dc0100000 Steering rollers Ø 50 mm
WD0100007 Float
Df0200100 / Df0200910 / Df0200600
Fa090003 Fixing clips for controller MP-888
Gb0700602 1.6 - 2.5A / Gb0700601 1.0 - 1.6A / Gb0700600 2.5 - 4.0A Motor Protection relay
GI0200003 Fuse 1A primary T1, 6.3 x 32 mm / GI0200001 Fuseholder big
Gb0101210 Contactor 32A
Gb0101210 Contactor 32A
GI0400500 20A / GI0400610 40A - Automatic cutout, 3-poles
Gb0101210 Contactor 32A pump motor (main contactor)
GI0200005 Fuse 6.3A, 6.3 x 32 mm / GI0200006 Fuse clipe 6.3A, WK 10mm (F27)
Gb0706021 Mini-relay 8-poles, complete with base
Gf0101200 Capillary pipe thermostat 80ºC - 370ºC
For use with water up to 90ºC, The TT-118 has a high cooling capacity making it suitable for use with rollers, calenders, plates, double walled vessels and other large consumers.
Explore The Product View Full Products RangeFa0800326 Digital temperature controller MP-888
Gk0300704 Switch unit "ON-OFF"
Gk0300704 Switch "ON-OFF" green
Gk0300704 Switch "ON-OFF" green
Gk0300704 Switch "ON-OFF" green
Gk0200100 Reversing switch VAC/pressure device
GK0600200 Switch for temperature measurement
Gn0700000 Lemo plug-in 2-pole
Gk0300100 Indication lamp motor overload (red)
Gk0300100 H 7 Lamp safety thermostat
Gk0300100 H 20 Lamp temperature deviation control (red)
Gk0300100 H 36 Lamp safety thermostat heating
Gk0300400 H 4/1 Lamp level control Unit off
Gk0300704 S 43 / H 43 Switch "ON-OFF" green
Gk0300100 H 63 Indication lamp flow control failure (red)
Gg0400100 P 2 Working hour meter
GG0300001 H 15 Horn
Gk0700800 Q 1 Main switch 63A
De0701603 Manometer -1 up to 6 bar
Wd0100000 Float
Gi0100001 F 15 Level switch for level control
Gi0100001 F 15/2 Level switch for level control
Df0200000 Solenoid valve
Df0200000 Solenoid valve
Df0200110 Solenoid valve R1/4"
Gm0100800 Heating element 3x380-420v 50Hz
De0100300 Water filter with mesh bottom
Dc0100400 Steering rollers 100 mm
Fa0900003 Fixing clips for controller MP-888
Gf0101200 F 10 / F 36 Capillary pipe thermostat 80C - 370C
GC0100610 T 1 Transformer control 70VA
Gl0200000 F 8 Fuse 1A secondary T1, 5 x 20 mm
Gl0200003 F 7 Fuse 1A primary T1, 6.3 x 32 mm
Automatic cutout 2A, 1-poles
Gb0706021 K 68 Mini-relay 8-poles, complete with base
Gb0705700 K 10 Relay ZRX1012
Gl0400600 F 24 Automatic cutout 32A, 3-poles
Bb0300100 Door locking
Gl0400600 F 24 Automatic cutout 32A, 3-poles
Gb0101211 K 1 Contactor 56A pump motor (main contactor)
Gb0101200 K 3 K 4 /-2/-3/-4 Contactor 32A
Gb0700900 F 1 Motor protection relay 4.0 - 6.0A
The TT-142 is a compact and rugged TCU for pressurised water circuits. The TT-142 provides safe and accurate temperature control for applications up to 140ºC.
Explore The Product View Full Products RangeFa0800326 Digital temperature controller MP-888
Gk0300704 Switch "ON-OFF" green
Gk0300704 Switch unit "ON-OFF"
Gk0300704 Switch unit "ON-OFF"
Gk0300704 Switch "ON-OFF" green
Gk0500100 S 10 Press button green
Gk0300100 H 6 Indication lamp motor overload (red)
Gk0300100 H 7 Lamp safety thermostat (red)
Gk0300100 H 20 Lamp temperature deviation control (red)
Gk0300100 H 36 Lamp safety thermostat heating
Gk0300300 H 4 Lamp level control (yellow)
Gk0300200 H 17 Lamp water cooling (gree)
Gk0300100 H 63 Indication lamp flow control failure (red)
GG0300001 H 15 Horn
Gk0700800 Q 1 Main switch 40A
De0701500 Manometer -1 up to 15 bar
DI0100115 Expansion tank, 2 litre
De0203500 Non-return valve 3/8"
De0501300 Safety Valve 1/2"
df0000028 Sensor flow measurement
De0203500 Non-return valve 3/8"
Df0200000 Solenoid valve R3/8"
Df0200000 Solenoid valve R3/8"
De0100400 Water filter 3/8 with mesh bottom
Dc0100400 Steering rollers 100 mm
Gf0101200 F 10 / F 36 Capillary pipe thermostat 80C - 370C
Fa0900003 Fixing clips for controller MP-888
Gl0200003 F 7 Fuse 1A primary T1, 6.3 x 32 mm
Gl0200000 F 8 Fuse 1A secondary T1, 5 x 20 mm
GC0100610 T 1 Transformer control 70VA
Gb0706021 K 68 Mini-relay 8-poles, complete with base
Gb0101211 K 1 Contactor 56A pump motor (main contactor)
gi0200100 Relay NK5272, 11-poles
Gl0200003 F 7 Fuse 1A primary T1, 6.3 x 32 mm
Bb0300100 Door locking
GG0300001 H 15 Horn
Gb0101211 K 1 Contactor 56A (heating 1)
Gb0700900 F 1 Motor protection relay 4.0 - 6.0A
Gk0701801 Q 1 Main switch 40A
This 5kW water chiller is designed for single machine applications at water temperatures from +10ºC up to +40ºC, and ambient temperatures up to +45ºC.
Explore The Product View Full Products RangeGK0300704: Switch on/off green 33 x 25mm (4 poles)
GK0300704: Switch on/off green 33 x 25mm (4 poles)
GK0300705: Switch ON/OFF green 33 x 25mm, 5 pole, 2 closing contacts
GK0300400: Double indication lamp yellow 33x25mm
FA0800326: Controller MP-888 new
GK0300100: Indication lamp red, 33x25mm
GK0300500: Double indication lamp red, 33x25mm
GK0300100: Indication lamp red, 33x25mm
GK0300100: Indication lamp red, 33x25mm
GK0300300: Indication lamp yellow 33x25mm
GK0300200: Green Indication Lamp 33x 25mm
GK0300100: Indication lamp red, 33x25mm
GK0200100: VAC-switch 3 switching levels, complete, front and back part
GK0701801: Main switch 40A
Serial number label (no part number)
BB0300100: Quick fastener for door switch cabinet
CA2000502 Manual refill
Df0200110 Solenoid valve 1/4"
Eb0201200 M 1 Pump type E with motor 0.75 kW
Df0000027 / DF0000040 F 64 Sensor flow measurement
Hb0104010 M3 Fan 250mm
Wa1000031 B 1 Thermocouple internal (Temperature probe)
Gm0100700 Heating element 3x200-230v 50/60Hz
Gf0101400 F 13 Adjustable safety thermostat
Dc0100400 Steering rollers 75mm
GC0100610 T 1 Transformer control 70VA
Gf0101400 F 13 Adjustable safety thermostat
Fa0900003 Fixing clips for controller MP-888
GG0300001 H 15 Horn
Gb0705800 K 23- / 2 Time delayed relay RR-900
Gb0700602 F 1 Motor protection relay 1.6 - 2.5 A
Gb0700800 F 3 Motor protection relay compressor 2.5 4.0 A
Gb0101210 K1Contactor 32A pump motor
Gb0101210 K3 Contactor 32A pump motor
Gl0400209 F 22 Automatic cutout 16A
Gk0701801 Q 1 Main switch 40A
Gk0200100 S 7 Reversing switch pump
Bb0300100 Door locking
Designed or use with oil up to 360ºC, the TT-390 TCU features Tool-Temp's C-571 high temperature leakproof pump.
Explore The Product View Full Products RangeFa0800326 Digital temperature controller MP-888
Gk0300704 Switch unit "ON-OFF"
Gk0300700 Switch heating 1 / 2 - 4
Gk0300700 Switch heating 1 / 2 - 4
GK0300705: Switch ON/OFF green 33 x 25mm, 5 pole, 2 closing contacts
Gk0600200 Switch Thermocoupler / Fe-Ko
Gk0200100 / Gk0200200 Switch Pump BAR / VAC
Gk0500100 Press button mould drainage
Gn0700000 Socket for thermocoupler / Fe-Ko
Gk0300100 Lamp motor control (red)
Gk0300500 Lamp safety thermostat (red)
Gk0300100 Lamp limit (red)
Gk0300100 Lamp safety thermostat for heating
Gk0300400 Lamp level control
Gk0300300 Lamp VAC (yellow)
Gk0300100 Lamp flow control (red)
Gg0400100 / Gg0400000 Working hour meter 50Hz
GG0300001 Horn
Gk0700800 Main switch 63A
De0701300 Manometer - 1 up to 9 bar / De0701200 Fixing clips for manometer
Df0000028 Sensor flow measurement
WB0202041 / WB0201085 Pump type Z with/ without pump
De0100300 Waterfilter 1" with mesh bottom
Dc0100400 Steering rolllers Ø 100 mm
De0202800 Non-return flap R 3/8"
Gf0101200 Level Control
Gi0100000 Level control
Df0200110 solenoid valve
De0200110 Non-return flap R 1"
Gf0101200 Capillary pipe thermostat 80ºC - up to 370ºC
GI0200003 Fuse 1A primary T1, 6.3 = x 32mm / GI0200001 Fuseholder small
GC0100610 Transformer control 70VA
Automatic cut-off 2A, 2-poles
GI0200000 Fuse 1A secondary T1, 5 x 20mm / GI0200002 Fuseholder small
GI0400400 Automatic cut-off 16A, 3-poles
GI0400400 Automatic cut-off 16A, 3-poles
GI0400400 Automatic cut-off 16A, 3-poles
GI0400400 Automatic cut-off 16A, 3-poles
Gb0101211 Contactor 56A pump motor (main contactor) / Gb0101212 Contactor 110A pump motor (main contactor)
Gb0700900 Thermal relay pump 4.0 - 6.0A
GB0101210 Contactor 32A
GB0101210 Contactor 32A
Fa0900003 Fixing clips for controller MP-888
Gg0400100 / Gg0400000 Working hour meter 50Hz
Bb0300100 Door locking
Bb0300100 Door locking
GG0300001 Horn
